LINE Element
XML Einrichten Version 1.3 > InvoiceMessage Element > INVOICE Element : LINE Element
Description
Posiitions of the invoice (INVOIC)
Namespace (none)
Diagram
DPPAddress Element DPPType Element Sequence DPP Element NumericValue Element TextValue Element OptionID Element Sequence Option Element CustomerName Element CustomerNumber Element Name Element Number Element GTIN Element Sequence FeatureID Element ParentFeatureLineNumber Element FeatureLineNumber Element Sequence OPT Element VatPercentageOfCondition Element AmountOfCondition Element PercentageRateOfCondition Element DscOfConditionType Element TypeOfCondition Element ConditionLevel Element ConditionIndicator Element Sequence CNDL Element LineText Element Sequence LTXT Element AdditionalDate Element AdditionalQuantity Element Qualifier Element Currency Element Value Element Sequence AdditionalLineAmount Element Qualifier Element PriceQuantity Element Currency Element Value Element Sequence AdditionalPrice Element DocRefLineNumber Element DocDate Element DocRefNumber Element Sequence AdditionalLineRef Element Sequence AdditionalLineReferences Element Currency Element Value Element Sequence VatBase Element VatPercentage Element Currency Element Value Element Sequence VatValue Element Sequence LineVat Element Currency Element Value Element Sequence NetLineAmount Element Currency Element Value Element Sequence DiscountsConditionsTotal Element PriceQuantity Element Currency Element Value Element Sequence NetUnitPrice Element PriceQuantity Element Currency Element Value Element Sequence GrossUnitPrice Element InvoiceQuantity Element MEA Element NumberOfPackages Element TypeOfPackaging Element DocRefLineNumber Element DocDate Element DocRefNumber Element Sequence OrderResponseLineRef Element DocRefLineNumber Element DocDate Element DocRefNumber Element Sequence DespatchAdviceLineRef Element DocRefLineNumber Element DocDate Element DocRefNumber Element Sequence OrderLineRef Element Commission Element ClassOfGoodsValue Element ClassOfGoodsFeature Element ClassOfGoodsType Element Sequence ClassOfGoods Element GoodsCountry Element TypeOfProduct Element BatchNumber Element CustomerName Element CustomerNumber Element Name Element Number Element GTIN Element Sequence ProductID Element CustomerName Element CustomerNumber Element Name Element Number Element GTIN Element Sequence SeriesID Element ParentLineItemNumber Element LineItemNumber Element Sequence LINE Element
Overview
LINE 1..∞
Posiitions of the invoice (INVOIC)
Sequence
LineItemNumber LineItemNumber Simple Type
ParentLineItemNumber optional LineItemNumber Simple Type
SeriesID optional ProductIdentifier Complex Type
Sequence
GTIN optional Restriction of xs:decimal
= EAN Code
Number optional Restriction of xs:string
Internal number defined by the manufacturer
Name optional Restriction of xs:string
Name
CustomerNumber optional Restriction of xs:string
Number at customers site
CustomerName optional Restriction of xs:string
Name at customers site
ProductID optional ProductIdentifier Complex Type
Sequence
GTIN optional Restriction of xs:decimal
= EAN Code
Number optional Restriction of xs:string
Internal number defined by the manufacturer
Name optional Restriction of xs:string
Name
CustomerNumber optional Restriction of xs:string
Number at customers site
CustomerName optional Restriction of xs:string
Name at customers site
BatchNumber optional BatchNumber Simple Type
TypeOfProduct optional TypeOfProduct Simple Type
GoodsCountry optional GoodsCountry Simple Type
ClassOfGoods optional ClassOfGoods Complex Type
Commission optional Commission Simple Type
OrderLineRef optional DocumentLineReference Complex Type
DespatchAdviceLineRef optional DocumentLineReference Complex Type
OrderResponseLineRef optional DocumentLineReference Complex Type
TypeOfPackaging optional TypeOfPackaging Simple Type
NumberOfPackages optional NumberOfPackages Simple Type
MEA 0..20 MEA Complex Type
Type optional Restriction of xs:string
Type if measurement
Code list (for articles and packaging):
AAE = Weight or Volumen
PD = Dimension
Use the following codes for special article measurements:
ABK = Outside dimension
ABL = Inside dimension
Y2E = Maximum dimension
Y3E = Minimum dimensionMinimalmaß z.B. Klappstuhl eingeklappt
Y4E = Lying dimension
Y5E = Sitting dimension
Dimension optional Restriction of xs:string
Gemessene Dimension
Verwenden Sie folgende Codes für Artikel und Packstücke:
DP = Tiefe
HT = Höhe
LN = Länge
WD = Breite
DI = Durchmesser
AAA = Netto Gewicht Ware inkl. Endkundenverpackung
AAB = Brutto Gewicht Ware inkl. Transportverpackung
AAF = Netto Gewicht Ware ohne jede Verpackung
ABJ = Volumen
Mesaured dimension
use this codes for articles and packaging:
DP = Depth
HT = Height
LN = Length
WD = Width
DI = Diameter
AAA = Net weight goods incl. end-consumer packaging
AAB = Gross weight goods incl. packaging for transporz
AAF = Net weight goods without any packaging
ABJ = Volume
Unit optional Unit Simple Type
InvoiceQuantity Quantity Complex Type
Unit optional Unit Simple Type
GrossUnitPrice optional GrossUnitPrice Complex Type
Sequence
Value xs:decimal
Currency Currency Simple Type
PriceQuantity Quantity Complex Type
Quantity related to the price information
Unit optional Unit Simple Type
NetUnitPrice optional NetUnitPrice Complex Type
Sequence
Value xs:decimal
Currency Currency Simple Type
PriceQuantity Quantity Complex Type
Quantity related to the price information
Unit optional Unit Simple Type
DiscountsConditionsTotal optional DiscountsConditionsTotal Complex Type
Sequence
NetLineAmount optional NetLineAmount Complex Type
Sequence
LineVat optional Vat Complex Type
Sequence
VatValue optional CurrencyValue Complex Type
Tax Amount
Sequence
VatPercentage VatPercentage Simple Type
Tax rate
VatBase optional CurrencyValue Complex Type
Vat base amount for a dedicated tax rate
Calculation: Sum of all Net Line Amounts - DiscountsConditionsTotal
Sequence
AdditionalLineReferences optional AdditionalLineReferences Complex Type
Sequence
AdditionalLineRef 0..∞ DocumentLineReferenceQualified Complex Type
AdditionalPrice 0..∞ PriceQualified Complex Type
Sequence
AdditionalLineAmount 0..∞ LineAmountQualified Complex Type
AdditionalQuantity 0..∞ QuantityQualified Complex Type
Qualifier optional QuantityQualifier Simple Type
Unit optional Unit Simple Type
AdditionalDate 0..∞ EDIDateQualified Complex Type
Qualifier optional EDIDateQualifier Simple Type
FormatCode optional EDIDateFormatCode Simple Type
LTXT 0..300 LTXT Complex Type
Sequence
LineText 1..999 Textinformation Complex Type
One line of text information according to the line information
Type required Restriction of xs:string
Freitext
Verwendung in Rechnungen
SUR = Text zur Entgeltminderung
REG = Text zur innergeimeischaftlichen Lieferung
AAB = Zahlungsbedingungen
AAI = Allgemeine Geschäftsbedingungen
AAR = Lieferbedingungen

Verwendung allgemein
TDT = Transportbemerkungen
ZZZ = Beidseitig vereinbart

Verwendung in der Reklamation
AFH = Reklamation
Free text
Use in invoices
SUR = Text about the reduction in wages
REG = text for intra-community delivery
AAB = Payment terms
AAI = General Terms and Conditions
AAR = delivery conditions

General use
TDT = Transport Notes
ZZZ = Mutually agreed

Use in the complaint
AFH = Complaint
CNDL 0..∞ CNDL Complex Type
Sequence
ConditionIndicator optional Restriction of xs:string
Condition Indicator
A = Allowence
C = Charge
ConditionLevel Restriction of xs:string
Condition level
TypeOfCondition Restriction of xs:string
Type of condition
DscOfConditionType optional Restriction of xs:string
Description of the condition
PercentageRateOfCondition optional Restriction of xs:decimal
Percentage value of the condition
AmountOfCondition optional Restriction of xs:decimal
Amount value of the condition
VatPercentageOfCondition VatPercentage Simple Type
Vat of the condition
OPT 0..∞ OPT Complex Type
Sequence
FeatureLineNumber Restriction of xs:int
Sequential number of the feature within a line
ParentFeatureLineNumber optional Restriction of xs:decimal
reference to a superior feature
FeatureID ProductIdentifier Complex Type
identification elements for a feature
Sequence
GTIN optional Restriction of xs:decimal
= EAN Code
Number optional Restriction of xs:string
Internal number defined by the manufacturer
Name optional Restriction of xs:string
Name
CustomerNumber optional Restriction of xs:string
Number at customers site
CustomerName optional Restriction of xs:string
Name at customers site
Option Option Complex Type
Description of the option according to the feature
Sequence
OptionID optional ProductIdentifier Complex Type
Sequence
GTIN optional Restriction of xs:decimal
= EAN Code
Number optional Restriction of xs:string
Internal number defined by the manufacturer
Name optional Restriction of xs:string
Name
CustomerNumber optional Restriction of xs:string
Number at customers site
CustomerName optional Restriction of xs:string
Name at customers site
TextValue optional
NumericValue optional UnitValue Complex Type
Unit optional Unit Simple Type
DPP 0..2 DPP Complex Type
Link to the digital product pass or digital zwin
Source
<xs:element name="LINE" minOccurs="1" maxOccurs="unbounded" xmlns:xs="http://www.w3.org/2001/XMLSchema">
  <xs:annotation>
    <xs:documentation xml:lang="de">Positionen der Rechnung (INVOIC) </xs:documentation>
    <xs:documentation xml:lang="en">Posiitions of the invoice (INVOIC)  </xs:documentation>
  </xs:annotation>
  <xs:complexType>
    <xs:sequence>
      <xs:element name="LineItemNumber" type="LineItemNumber" minOccurs="1" />
      <xs:element name="ParentLineItemNumber" type="LineItemNumber" minOccurs="0" />
      <xs:element name="SeriesID" type="ProductIdentifier" minOccurs="0" />
      <xs:element name="ProductID" type="ProductIdentifier" minOccurs="0" />
      <xs:element name="BatchNumber" type="BatchNumber" minOccurs="0" />
      <xs:element name="TypeOfProduct" type="TypeOfProduct" minOccurs="0" />
      <xs:element name="GoodsCountry" type="GoodsCountry" minOccurs="0" />
      <xs:element name="ClassOfGoods" type="ClassOfGoods" minOccurs="0" />
      <xs:element name="Commission" type="Commission" minOccurs="0" />
      <xs:element name="OrderLineRef" type="DocumentLineReference" minOccurs="0" />
      <xs:element name="DespatchAdviceLineRef" type="DocumentLineReference" minOccurs="0" />
      <xs:element name="OrderResponseLineRef" type="DocumentLineReference" minOccurs="0" />
      <xs:element name="TypeOfPackaging" type="TypeOfPackaging" minOccurs="0" />
      <xs:element name="NumberOfPackages" type="NumberOfPackages" minOccurs="0" />
      <xs:element name="MEA" type="MEA" minOccurs="0" maxOccurs="20" />
      <xs:element name="InvoiceQuantity" type="Quantity" />
      <xs:element name="GrossUnitPrice" type="GrossUnitPrice" minOccurs="0" />
      <xs:element name="NetUnitPrice" type="NetUnitPrice" minOccurs="0" />
      <!-- DE:<xs:element name="GrossLineAmount"       type="GrossLineAmount"       minOccurs="0" />   -->
      <xs:element name="DiscountsConditionsTotal" type="DiscountsConditionsTotal" minOccurs="0" />
      <xs:element name="NetLineAmount" type="NetLineAmount" minOccurs="0" maxOccurs="1" />
      <xs:element name="LineVat" type="Vat" minOccurs="0" />
      <xs:element name="AdditionalLineReferences" type="AdditionalLineReferences" minOccurs="0" maxOccurs="1" />
      <xs:element name="LTXT" type="LTXT" minOccurs="0" maxOccurs="300" />
      <xs:element name="CNDL" type="CNDL" minOccurs="0" maxOccurs="unbounded" />
      <xs:element name="OPT" type="OPT" minOccurs="0" maxOccurs="unbounded" />
    </xs:sequence>
  </xs:complexType>
</xs:element>
